Technical Specification
|
|
|
| CHARACTERISITICS |
EURO STANDARD |
OUR VALUE |
| DIMENSION & SURFACE QUALITY |
|
|
| Dimension & surface quality |
± 0.5% |
± 0.2% |
| Deviation in thickness |
± 0.6% |
± 0.2% |
| Straightness of sides |
± 0.3% |
± 0.2% |
| Rectangularity |
± 0.5% |
± 0.3% |
| Surface Flatness |
± 0.5% |
± 0.3% |
| Surface Quality |
± Min 95% |
± Min 96% |
| PHYSICAL PROPERTIES |
|
|
| Water Absorption |
> 10% |
>14-17% |
| Bend Strength |
> 150 Kg./Cm |
> 200-250Kg./Cm |
| Scratch Hardness (Moh’s) |
Min 3 |
Min 3 |
| Crazing |
1 Cycle |
No Craxing at 2 Cycle |
| CHEMICAL PROPERTIES |
|
|
| Staining Resistance |
Min Class 2 |
Resistant to all acids and alkalies |
| Household Chemical |
Min Class B |
Household chemicals except hydro fluric acid |
| THERMAL PROPERTIES |
|
|
| Thermal Shoke |
Resistant to 10 Cycle |
Conforms |
| Thermal Expansion |
Max-9E-06 |
Conforms |
Packing Details For Export
| DIMENSION |
TILES PER BOX(Pcs) |
AREA COVERAGE PER BOX(SQ.FT) APPROX |
WEIGHT PER BOX(KG) APPROX |
THICKNESS(MM) APPROX |
| 100x300mm |
33 |
0.99 |
13.5 |
8 |
| 100x200mm |
50 |
1 |
13 |
8 |
| 75x300mm |
44 |
0.99 |
14 |
8 |
